MB-86 Casement is an aluminium system for outward-opening windows. It allows top-hung and side-hung casements as well as fixed lights, with an additional SI insulator as standard. RS Concept, a Polish window and door supplier, quotes MB-86 Casement windows for housing projects and private homes, built to your sizes and opening types. The frame has a construction depth of 77 mm and the sash 86 mm. The standard glazing unit is 4/16Ar/4/16Ar/4, and the frame accepts glazing from 14 to 60 mm. Hardware comes with roller or scissor hinges in several variants.
Send us a window schedule or drawings, and we will prepare a quote. Lead time from 1 month, confirmed with the quotation.
Key features
- Outward-opening aluminium window system
- Types: fixed, top-hung, side-hung
- Frame depth 77 mm, sash depth 86 mm
- Standard glazing unit 4/16Ar/4/16Ar/4
- Glazing thickness in the frame from 14 to 60 mm
- Additional SI insulator as standard
- Hinges: roller or scissor hinges in several variants
- Duo-colour varnishing available
- Full RAL K7 colour palette; other colours on request (powder code)
Available on request
- Sizes and opening types to your window schedule or drawings
- Glazing units within the thickness range above (double or triple)
- Hinges: roller or scissor hinges in several variants; duo-colour finish
- Colours: full RAL K7 palette; other colours via powder code
- Technical data and profile drawings for your project
Lead time
From 1 month, confirmed with each quotation.
