MB-60 is a 60 mm aluminium system with polyamide thermal breaks, used for windows, doors, vestibules, shop windows and other glazed
structures. RS Concept, a Polish window and door supplier, quotes MB-60 windows and doors to your sizes and opening types for housing projects, offices and shop fronts. The system comes in several versions: MB-60, MB-60 HI, MB-60 US, MB-60 US HI and MB-60 Pivot, so the profile can be matched to the thermal level and the type of element. Colours come from the full RAL K7 palette, and other colours can be quoted on request. Send us a window schedule or drawings, and we will prepare a quote. Lead time from 1 month, confirmed with the quotation.
Key features
- Aluminium profile system, construction depth 60 mm
- Frame depth 60 mm (door/window); sash depth 60 mm (door) / 69 mm (window)
- Thermal breaks made of glass-fibre reinforced polyamide (MB-60 / MB-60 HI)
- Versions: MB-60, MB-60 HI, MB-60 US, MB-60 US HI, MB-60 Pivot
- Glazing units up to 41 mm (fixed window) / up to 50 mm (operable window)
- Maximum window size: height up to 2400 mm, width up to 1250 mm
- Maximum sash weight 120 kg (door) / 130 kg (window)
- Full RAL K7 colour palette; other colours on request (powder code)
Available on request
- Sizes and opening types to your window schedule or drawings
- Glazing units within the thickness range above (double or triple)
- Version: MB-60, MB-60 HI, MB-60 US, MB-60 US HI or MB-60 Pivot
- Colours: full RAL K7 palette; other colours via powder code
- Technical data and profile drawings for your project
Lead time
From 1 month, confirmed with each quotation.
